The latest 5G bands recommended by North American mobile operator alliance PTCRB
The division and combination of 5G mobile communication technology is much more complex than 4G. The common large frequency bands are FR1 and FR2, FR1 and FR2 are SA and NSA, NSA is combined with 4G, and the working mode is TDD and FDD, so the confirmation of frequency bands and system is particularly important.
According to the latest frequency bands specification PTCRB published,obtained by Deeplight in January 2022, it is instructive for manufacturers to confirm the frequency bands system.
Part 1
PTCRB 5G NR FR1 SA bands FDD
|
n2 |
n5 |
n7 |
n12 |
n14 |
n25 |
n26 |
n30 |
n66 |
n70 |
n71 |
Part 2
PTCRB 5G NR FR1 SA bands TDD
|
n38 |
n41 |
n48 |
n77 |
n78 |
Part 3
PTCRB 5G NR FR1 SA SDL bands FDD
|
n29 |
Part 4
PTCRB 5G NR FR1 NSA bands FDD
|
n2 |
n5 |
n7 |
n12 |
n25 |
n30 |
n66 |
n71 |
Part 5
PTCRB 5G NR FR1 NSA bands TDD
|
n38 |
n41 |
n77 |
n78 |
Part 6
PTCRB 5G NR FR2 NSA bands TDD
|
n257 |
n258 |
n260 |
n261 |
With the evolution of 5G technology and the adjustment of technology by North American operators, follow-up frequency band information will continue to be adjusted. Welcome to contact Deeplight for information such as operator certification and North American PTCRB network access, GCF certification and other information.
The technical services we provide can assist customers to simultaneously complete a series of testing and certification projects ranging from regulatory certification, alliance certification, network access certification, and operator certification.
