Beidou Navigation Satellite products Certification Implementation Rules
The Beidou Navigation Satellite System is a Global Navigation Satellite System (GNSS) independently constructed and operated by China. It is an important space-time infrastructure that provides all-weather, all-day, high-precision positioning, navigation and timing services for global users. In order to further improve the quality of Beidou Basic Products such as chips, modules, antennas, and boards, and ensure the wide application of Beidou Navigation Satellite System in various fields and industries.
The State Administration for Market Regulation strengthens the organization, implementation, supervision and management of certification work, and cooperates with the competent authorities for the construction and development of Beidou Navigation Satellite System to increase the acceptance of certification results to create a favorable environment for the development of Beidou Basic Products.
Beidou Basic Product Logo
Beidou Navigation Satellite System Logo
(Any unit or individual shall not forge, alter, use fraudulently, trade or transfer the certification mark.)
The certification catalog and certification rules are published separately by the State Administration for Market Regulation.
|
Serial number
|
Product categories
|
Product description
|
Certification basis
|
|
|
1
|
Chip products
|
Dual-frequency multi-system high-precision RF baseband integrated chip
|
This product is an integrated RF baseband integrated chip for various low-cost and high-precision applications. It supports navigation signals such as BDSB1I/B1C/B2a, GPSL1/L5, Galileo E1/E5, etc. It has certain anti-multipath and anti-jamming capabilities, and can realize dual-frequency multi-mode high-precision joint positioning.
|
BDS-JSCS-2021-002 "Technical requirements and test methods for Beidou Navigation Satellite System civil global signal dual-frequency multi-system high-precision RF baseband integrated chip"
|
|
2
|
RNSS RF baseband integrated chip
|
This product is an integrated RF baseband integrated chip for various low-cost common navigation applications. It supports navigation signals such as BDSB1I/B1C and GPSL1C/A, supports differential enhancement, combined navigation, multi-tone interference cancellation and other functions, and can realize single-system positioning and multi-system joint positioning.
|
BDS-JSCS-2021-001 "Beidou Navigation Satellite System Civil Global Signal RNSS RF Baseband Integrated Chip Product Technical Requirements and Test Methods"
|
|
|
3
|
Multi-mode multi-frequency broadband RF chip
|
This product is a multi-mode and multi-frequency broadband radio frequency chip for various high-precision navigation applications. It can support broadband reception of all civil frequency signals of BDS, GPS, Galileo, GLONASS and other systems, and has the characteristics of high integration, flexible configuration of bandwidth and center frequency.
|
BDS-JSCS-2021-003 "Technical requirements and test methods for civil global signal multi-mode and multi-frequency broadband RF chips of Beidou Navigation Satellite System"
|
|
|
4
|
Beidou-3 short message communication SIM card
|
This product is a SIM card product for Beidou short message communication terminal network access authentication application. Support Beidou Navigation Satellite System civilian short message terminals to access Beidou network user identity authentication and information encryption and decryption functions, including chip and in-chip operating system (COS).
|
GB/T 22186 "Information Security Technology - IC Card Chip Security Technical Requirements with Central Processing Unit" GB/T20276 "Information Security Technology - IC Card Embedded Software Security Technical Requirements with Central Processing Unit"
|
|
|
5
|
Wireless products
|
Multi-mode multi-frequency high-precision antenna
|
This product is a miniaturized multi-mode multi-frequency high-precision antenna for various low-cost and high-precision applications. It supports the reception of all civil frequency signals of BDS, GPS, Galileo, GLONASS and other systems, and provides good phase center stability and gain performance in a small size.
|
BDS-JSCS-2021-004 "Technical requirements and test methods for Beidou Navigation Satellite System civil global signal multimode and multifrequency high-precision antenna products"
|
|
6
|
Module products
|
Multi-mode and multi-frequency navigation module
|
This product is a miniaturized multi-mode and multi-frequency navigation module for various low-cost and high-precision applications. Support BDS, GPS, Galileo, GLONASS and other systems for all civil frequency point navigation signals, with RTK and PPP high-precision positioning functions, with the advantages of small size and easy integration.
|
BDS-JSCS-2021-006 "Beidou Navigation Satellite System Civilian Global Signal Multimode and Multifrequency Navigation Module Product Technical Requirements and Test Methods"
|
|
7
|
Board products
|
Multi-mode multi-frequency high-precision board
|
This product is a multi-mode and multi-frequency high-precision board for various high-precision applications. It supports all civil frequency point navigation signals of BDS, GPS, Galileo, GLONASS and other systems, can output high-quality carrier phase and pseudo-range observations, and has RTK, PPP high-precision positioning and satellite-based enhancement functions.
|
BDS-JSCS-2021-005 "Technical requirements and test methods for Beidou Navigation Satellite System civil global signal multimode and multifrequency high-precision board products"
|
The first batch of certification catalogues
Beidou Navigation Satellite products (terminal equipment class) certification implementation rules
The certification mode is: type test + initial factory inspection + post-certification supervision
Applicable to product performance and reliability certification of Beidou Navigation Satellite products (terminal equipment), such as navigation, RDSS, measurement, timing and other terminal equipment (product reliability assessment is not included during the pilot period).
1. The basic steps of certification include:
a) Certification application
b) Product type test
c) Initial factory inspection
d) Evaluation and approval of certification results
e) Supervision after certification
f) Review
2. Type test based on standard
Navigation BD 420010-2015 General Specification for BeiDou/Global Navigation Satellite System (GNSS) Navigation Equipment
RDSS type CHB5.6 "Beidou User Equipment Verification Regulations"
Survey-type BD 420009-2015 General specification for BeiDou/Global Navigation Satellite System (GNSS) survey-type receivers
Positioning type BD 420011-2015 Beidou/Global Navigation Satellite System (GNSS) Positioning Equipment General Specification 4.2.2
3. Detection time
The testing time is generally 30 working days, starting from the receipt of the sample and the testing fee. If the project is not qualified, the rectification time is generally not more than 2 months
4. Initial factory inspection
For enterprises that have passed CCC certification, ISO 9001 or GJB 9001 certification and the certificate is within the validity period, the factory inspection can be appropriately simplified.
5. Certificate validity period
After the completion of the type test and factory inspection, the certificate will be issued within 30 days for those that meet the certification requirements.
The certification certificate is valid for 3 years, and the validity of the certificate is maintained through regular supervision.
6. Use of certification marks
The certificate holder can apply for the record or purchase the certification mark according to the "Administrative Measures of Beidou Navigation Satellite Products Certification Mark" of China Beidou Navigation Satellite products Testing and Certification Alliance. The use of the mark shall comply with the "Administrative Measures for the Certification Mark of Beidou Navigation Satellite products".
(Deformation marks and text descriptions are not allowed.)
7. Certification fee
The certification fee is charged according to the relevant regulations of The 54th Research Institute of China Electronics Technology Group Corporation.
The above is Deeplight interpretation of the implementation rules of Beidou Navigation Satellite products certification. You are welcome to come and consult, and we will provide you with professional, reliable and accurate testing services.
